ABS05-32.768KHZ-T专用于实时时钟应用
来源：http://www.hneyq.com 作者：亿金电子 2023年04月19
Abracon是无源元件领域的行业领导者，提供频率控制和定时设备、射频和天线产品以及电感和连接解决方案。Abracon的石英晶振提供低ESR规格和低CL选项，以应对节能MCU和便携式通信芯片组市场趋势。为了支持这种功耗降低，许多片内振荡器的输出驱动有限，使用ESR & CL规格更高的标准石英晶体往往无法维持振荡。Abracon的W系列石英晶体专为微功率应用而设计，可克服这些挑战。Abracon晶振提供各种封装尺寸、频率和性能条件的石英晶体，如工业级和汽车级。ABS05音叉晶体ABS05-32.768KHZ-T专用于实时时钟应用
| 原厂编码 | 品牌 | 型号 | 系列 | 频率 | 包装/封装 |
| ABS25-32.768KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SOJ, 5.50mm pitch |
| ABS25-32.768KHZ-6-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SOJ, 5.50mm pitch |
| ABS07-32.768KHZ-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS25-32.768KHZ-1-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SOJ, 5.50mm pitch |
| ABS25-32.768KHZ-6-1-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SOJ, 5.50mm pitch |
| ABS07-120-32.768KHZ-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07-32.768KHZ-7-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 时钟晶体 | 2-SMD, No Lead |
| ABS07-32.768KHZ-9-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS13-32.768KHZ-T | Abracon晶振 | ABS13 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SMD, Flat Lead, 3 Leads |
| ABS07-32.768KHZ-7-1-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07-32.768KHZ-9-1-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07-32.768KHZ-6-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS10-32.768KHZ-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS10-32.768KHZ-7-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS10-32.768KHZ-9-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07-32.768KHZ-1-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS09-32.768KHZ-9-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS09-32.768KHZ-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS10-32.768KHZ-1-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
ABS05音叉晶体ABS05-32.768KHZ-T专用于实时时钟应用，Abracon的ABS音叉晶振系列被广泛应用于从工业和医疗电子产品到消费物联网设备。这些音叉晶体适合需要小尺寸的RTC电路的时间管理。ABS05系列音叉具有低功耗特性，可在许多应用中延长电池寿命。在生产相同性能的同时，Abracon现已开发并推出了4.0pF电镀其微型ABS05系列的版本。这种4.0pF电镀选项将使任何电路的功耗更低，启动速度明显更快。
ABS05系列设计有4.0pF的超低负载电容选项，通过特殊的过程控制技术实现；低功耗振荡器电路的关键因素。当作为实时时钟(RTC)和最终发射频率的一部分时，这些技术使谐振频率的精度最大化。
ABS05音叉晶体ABS05-32.768KHZ-T专用于实时时钟应用，这些晶体还具有1.6 x 1.0mm毫米的超小型尺寸，采用4焊盘SMD封装石英晶体谐振器。尽管尺寸超小，但ABS05系列的最大等效串联电阻(ESR)仅为90kω。可用的频率公差为30ppm、25ppm和20ppm，根据要求可提供10ppm。对于尺寸要求严格的新设计，ABS05是理想的解决方案。
| ABS09-32.768KHZ-7-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07L-32.768KHZ-T | Abracon晶振 | ABS07L | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS09-32.768KHZ-1-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS25-32.768KHZ-4-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32.768kHz | 4-SOJ, 5.50mm pitch |
| ABS25-32.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 32kHz | 4-SOJ, 5.50mm pitch |
| ABS25-38.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 38kHz | 4-SOJ, 5.50mm pitch |
| ABS06L-32.768KHZ-T | Abracon晶振 | ABS06L | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07-32.768KHZ-4-T | Abracon晶振 | ABS07 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS25-60.000KHZ-T | Abracon晶振 | ABS25 | kHz Crystal (Tuning Fork) | 60kHz | 4-SOJ, 5.50mm pitch |
| ABS25-100.000KHZ-T | 石英晶振 | ABS25 | kHz Crystal (Tuning Fork) | 100kHz | 4-SOJ, 5.50mm pitch |
| ABS05-32.768KHZ-T | Abracon晶振 | ABS05 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS05-32.768KHZ-9-T | Abracon晶振 | ABS05 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS10-32.768KHZ-4-T | Abracon晶振 | ABS10 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS09-32.768KHZ-4-T | Abracon晶振 | ABS09 | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-D-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-D-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-J-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-J-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-K-2-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
| ABS07W-32.768KHZ-K-1-T | Abracon晶振 | ABS07W | kHz Crystal (Tuning Fork) | 32.768kHz | 2-SMD, No Lead |
ABS05音叉晶体ABS05-32.768KHZ-T专用于实时时钟应用
特征：小型音叉晶体(1.60 x 1.00 x 0.50 mm封装)，薄型-高度受限设计的理想选择，低负载电容4pF，设定公差为20 ppm/ 10ppm，工业应用的扩展温度范围为-40°C至+85°C
应用程序：无线模块，物联网，超低功耗-实时时钟，蓝牙/蓝牙低能耗(BLE)，可穿戴设备，商业和工业应用
